2 1/2 Inch HDPE Sweeps

Manufactured from flexible high-density polyethylene (HDPE), sweeps enable changes in direction and elevation in a longer run of conduit. Sweeps can be used in a variety of applications, including telecommunications, data centers, and power networks. Available in sizes from 2” to 8” outer diameter (OD) with standard bend angles of 45° and 90° with 36” radius and custom options available upon request. Products are available in black (typical) or gray and are UV-grade.
Manufactured from flexible high-density polyethylene (HDPE), sweeps enable changes in direction and elevation in a longer run of conduit. Sweeps can be used in a variety of applications, including telecommunications, data centers, and power networks. Available in sizes from 2” to 8” outer diameter (OD) with standard bend angles of 45° and 90° with 36” radius and custom options available upon request. Products are available in black (typical) or gray and are UV-grade.

Features

  • Manufactured from flexible HDPE
  • Excellent low-temperature properties allows for installation in cold climates
  • Standard bend angles of 45° and 90° with 36" Radius
  • Co-extruded with SILICORE® ULF permanent lining to reduce friction on cable installs
  • Certain sizes listed to UL 651A
  • Custom options available upon request
Ask your question
2 1/2 Inch HDPE Sweeps

Technical Details

Part # Description Radius (in.) Packaging Amount of Items per Pallet
20094431 2 1/2" SDR 13.5 - 45 Degree 36 Pallet 150
20094432 2 1/2" SDR 13.5 - 90 Degree 36 Pallet 150
20094905 2 1/2" SDR 13.5 - 90 Degree Gray 36 Pallet 150
20094906 2 1/2" SCH 40 - 90 Degree 36 Pallet 150

Downloads

Specifications
Sweeps 1.25
