Polyester Tape

Bull-Line 100% Polyester Pull Tape provides a competitive solution for applications that require a high tensile strength and low elongation. Bull-Line Pull Tape is lightweight and has good blowability. Bull-Line Pull Tape has low burn through resistance in comparison to other brands. An added benefit of all Bull-Line Pull Tapes are the durable print and sequential markings, in both feet or meters, for accurate locating during installation. Bull-Line Pull Tape is made in the USA.

Features

  • Stiff-Tape™ lubricated coating
  • Best burn-through (conduit cutting) resistance
  • Good blowability into conduit
  • Accurate sequential foot or meter markings
  • Can be factory pre-installed into conduit
  • Available on reels in a wide variety of continuous lengths
  • Tensile strength range 500 lb - 6,000 lb

Technical Specifications

Select Tensile Strength

500 lb
1000 lb
1250 lb
1800 lb
2500 lb
4000 lb
6000 lb
Part # Description Approx Tape Width (in.) Length (ft) Length (m) Reel type Reel Size (in) Reel Weight (lb) # Reels/Pallet Total Pallet Weight (lb)
20000134 Bull-Line Polyester Tape WP05 1000ft 0.25 " 1000 ' Wood 8 " 4.9 lb 100 541 lb
20000044 Bull-Line Polyester Tape WP05 3000ft 0.25 " 3000 ' Plastic 12 " 12.4 lb 48 646.2 lb
20000045 Bull-Line Polyester Tape WP05 5000ft 0.25 " 5000 ' Plastic 12 " 19.2 lb 48 972.6 lb
20000043 Bull-Line Polyester Tape WP05 10000ft 0.25 " 10000 ' Plastic 14 " 37.5 lb 18 726 lb
20000136 Bull-Line Polyester Tape WP10 1000ft 0.4375 " 1000 ' Wood 8 " 7.8 lb 100 831 lb
20000047 Bull-Line Polyester Tape WP10 3000ft 0.4375 " 3000 ' Plastic 12 " 21.1 lb 48 1063.8 lb
20000048 Bull-Line Polyester Tape WP10 5000ft 0.4375 " 5000 ' Plastic 14 " 35 lb 36 1311 lb
20000139 Bull-Line Polyester Tape WP12 500ft 0.5 " 500 ' Wood 8 " 5.4 lb 100 586 lb
20000138 Bull-Line Polyester Tape WP12 1000ft 0.5 " 1000 ' Wood 8 " 9.2 lb 100 971 lb
20000394 Bull-Line Polyester Tape WP12 1500ft 0.5 " 1500 ' Plastic 12 " 13.8 lb 48 711 lb
20000052 Bull-Line Polyester Tape WP12 3000ft 0.5 " 3000 ' Plastic 12 " 25.3 lb 48 1265.4 lb
20000054 Bull-Line Polyester Tape WP12 5000ft 0.5 " 5000 ' Plastic 14 " 42 lb 36 1563 lb
20000051 Bull-Line Polyester Tape WP12 10000ft 0.5 " 10000 ' Plastic 16 " 81.4 lb 18 1516.2 lb
20005112 Bull-Line Polyester Tape WP12 15000ft 0.5 " 15000 ' Wood 24 " 129.5 lb 8 1087 lb
20005113 Bull-Line Polyester Tape WP12 20000ft 0.5 " 20000 ' Wood 24 " 168 lb 8 1395 lb
20002202 Bull-Line Polyester Tape WP12 900m 0.5 " 900 m Plastic 12 " 24.9 lb 48 1247.9 lb
20000406 Bull-Line Polyester Tape WP12 1000m 0.5 " 1000 m Plastic 14 " 28.8 lb 36 1086.4 lb
20002199 Bull-Line Polyester Tape WP12 2000m 0.5 " 2000 m Plastic 16 " 54.9 lb 18 1039.6 lb
20000142 Bull-Line Polyester Tape WP18 500ft 0.625 " 500 ' Wood 8 " 6.8 lb 100 726 lb
20000065 Bull-Line Polyester Tape WP18 1000ft 0.625 " 1000 ' Plastic 12 " 12.7 lb 48 660.6 lb
20000395 Bull-Line Polyester Tape WP18 1500ft 0.625 " 1500 ' Plastic 12 " 18 lb 48 912.6 lb
20000068 Bull-Line Polyester Tape WP18 3000ft 0.625 " 3000 ' Plastic 13 " 33.8 lb 36 1267.8 lb
20000070 Bull-Line Polyester Tape WP18 5000ft 0.625 " 5000 ' Plastic 16 " 56.9 lb 18 1075.2 lb
20000152 Bull-Line Polyester Tape WP18 6500ft 0.625 " 6500 ' Plastic 16 " 72.7 lb 18 1358.7 lb
20000389 Bull-Line Polyester Tape WP18 10000ft 0.625 " 10000 ' Plastic 18 " 110 lb 10 1151 lb
20000383 Bull-Line Polyester Tape WP18 12000ft 0.625 " 12000 ' Plastic 22 " 133.4 lb 8 1118.2 lb
20000262 Bull-Line Polyester Tape WP18 900m 13" reel 0.625 " 900 m Plastic 14 " 34.5 lb 36 1293.1 lb
20000128 Bull-Line Polyester Tape WP18 900m 14" reel 0.625 " 900 m Wood 14 " 34.5 lb 36 1242.1 lb
20000066 Bull-Line Polyester Tape WP18 1000m 0.625 " 1000 m Plastic 14 " 37.9 lb 18 734.1 lb
20000143 Bull-Line Polyester Tape WP25 500ft 0.75 " 500 ' Wood 8 " 8.6 lb 100 911 lb
20000073 Bull-Line Polyester Tape WP25 1000ft 0.75 " 1000 ' Plastic 12 " 16.4 lb 48 838.2 lb
20000075 Bull-Line Polyester Tape WP25 1500ft 0.75 " 1500 ' Plastic 12 " 23.5 lb 48 1179 lb
20003875 Bull-Line Polyester Tape WP25 2000ft 0.75 " 2000 ' Plastic 18 " 73.9 lb 10 790 lb
20000077 Bull-Line Polyester Tape WP25 3000ft 0.75 " 3000 ' Plastic 14 " 46.1 lb 36 1710.6 lb
20000080 Bull-Line Polyester Tape WP25 5000ft 0.75 " 5000 ' Plastic 16 " 75.4 lb 18 1408.2 lb
20002183 Bull-Line Polyester Tape WP25 6000ft 0.75 " 6000 ' Plastic 18 " 90.2 lb 10 953 lb
20000082 Bull-Line Polyester Tape WP25 6500ft 0.75 " 6500 ' Plastic 18 " 97.3 lb 10 1024 lb
20000074 Bull-Line Polyester Tape WP25 10000ft 0.75 " 10000 ' Wood 24 " 156 lb 4 675 lb
20000083 Bull-Line Polyester Tape WP25 900m 0.75 " 900 m Wood 18 " 49.7 lb 8 397.8 lb
20005022 Bull-Line Polyester Tape WP25 1000m 0.75 " 1000 m Plastic 16 " 51 lb 18 968.8 lb
20003872 Bull-Line Polyester Tape WP25 1800m 0.75 " 1800 m Wood 18 " 91.7 lb 8 733.3 lb
20005178 Bull-Line Polyester Tape WP25 2000m 0.75 " 2000 m Plastic 18 " 98.2 lb 10 1032.8 lb
20000076 Bull-Line Polyester Tape WP25 2000m 0.75 " 2000 m Wood 18 " 101 lb 8 807.8 lb
20000153 Bull-Line Polyester Tape WP40 1000ft 0.875 " 1000 ' Plastic 13 " 28.7 lb 36 1084.2 lb
20000161 Bull-Line Polyester Tape WP40 3000ft 0.875 " 3000 ' Plastic 16 " 83.6 lb 18 1555.8 lb
20000160 Bull-Line Polyester Tape WP40 5000ft 0.875 " 5000 ' Plastic 18 " 137 lb 10 1421 lb
20000144 Bull-Line Polyester Tape WP60 500ft 1.125 " 500 ' Plastic 12 " 22 lb 48 1107 lb
20000154 Bull-Line Polyester Tape WP60 1000ft 1.125 " 1000 ' Plastic 14 " 43.1 lb 36 1602.6 lb
20002182 Bull-Line Polyester Tape WP60 1500ft 1.125 " 1500 ' Plastic 16 " 63.8 lb 18 1199.4 lb
20000363 Bull-Line Polyester Tape WP60 2500ft 1.125 " 2500 ' Wood 18 " 106.8 lb 10 1119 lb
20000149 Bull-Line Polyester Tape WP60 3000ft 1.125 " 3000 ' Wood 18 " 126.6 lb 10 1317 lb
20000321 Bull-Line Polyester Tape WP60 5000ft 1.125 " 5000 ' Wood 24 " 212 lb 4 899 lb
20000165 Bull-Line Polyester Tape WP60 6000ft 1.125 " 6000 ' Wood 24 " 251.6 lb 4 1057.4 lb

Other Bull-Line Pull Tape Options
